Decoding & Display
4*HDMITM output@1080P; HDMITM1 supports 8K
HDMITM1, HDMITM2 and HDMITM3 support 4K
Supports PS, RTP, TS, ES encapsulation formats (in platform running mode)
Supports NTSC & PAL video formats
H.265 HP/MP/BP and H.264 HP/MP/BP
4CH 16MP@30fps or 8CH 8MP@30fps or 12 CH 5MP@30fps or 20CH 3MP@30fps or 32CH 1080P@30fps
G.711A/G.711U audio compression
Stream Mode
A&V streams can be acquired actively and passively
A&V streams can be directly acquired from TVT IPC/DVR/NVR by SDK private protocol
A&V streams can be acquired form NVMS platform or encoding devices by RTSP/ RTP protocol
A&V streams can be acquired from IPC by ONVIF protocol Device Management
Supports multi-level device control (master-slave mode)
A maximum of 64 decoders can be manageable
Decoding Control
Supports live view and playback decoding
1/4/9/16/25/36/64 screen display mode
Window opening, roaming
View cameras or camera groups in sequence
Access
Provides HTTP API protocol for the third-party
Supports platform running mode and device running mode
Operation and Maintenance
Supports device search
Supports WEB client access, configuration and management
Supports time zone, time and date settings
Supports data port and HTTP port settings
Supports data backup and restoration
Supports remote reboot and one-button reset
Supports online and U-disk upgrade
Supports dual gigabit Ethernet ports, load balancing
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
System | CPU | RK3588 |
OS | Embedded Linux | |
Memory | LPDDR4 8GB; 16 GB EMMC | |
Video | HDMITM Output | HDMITM1: 7680×4320, 3840×2160, 1920×1080, 1280×1024 |
HDMITM2: 3840×2160, 1920×1080 , 1280×1024 | ||
HDMITM3: 3840×2160, 1920×1080, 1280×1024 | ||
HDMITM4: 1920×1080, 1280×1024 | ||
VGA Output | VGA×1: 1920×1080, 1280×1024 (VGA can output the same video source with HDMITM 1/2/3) | |
Multi-screen Display | Output 1/2/3/4: 1/4/9/16/25/36/64 | |
HDMITM Input | 1CH HDMITM input: supports 3840×2160, 1920×1080, 1600×1200, 1680×1050, | |
Video Compression | H.264/H.265/MJPEG | |
Audio | HDMITM Input | No |
HDMITM Output | Yes | |
Local Input | RCA×1 (currently no function) | |
Local Output | RCA×1 (monophonic) | |
Audio Compression | G.711(U/A) | |
Decoding Capability | Resolution | 16MP, 12MP, 8MP, 5MP, 4MP, 3MP, 1080P, 720P, D1, CIF |
Decoding Capability | 4CH 16MP@30fps or 8CH 8MP@30fps or 12 CH 5MP@30fps or 20CH 3MP@30fps | |
External | Network Interface | 10M/100M/1000M RJ45 ×2 |
USB Interface | USB3.0×1，USB2.0×2 | |
Alarm Interface | 4CH alarm input; 4CH alarm output | |
USB Console Interface | 1 | |
Others | Power | DC12V 4A |
Power Consumption | 48 W | |
Working Environment | –10°C - +50°C | |
Working Humidity | 10% ~ 90% | |
Dimensions | 380 ( W ) ×268 ( D ) × 45 ( H ) |
