8 / 16 CH TVI / AHD /CVI 8MP / 5MP / 4MP / 3MP / 1080P / 720P / WD1
8 / 16 CH DVRs support 8 / 8 CH 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P
IP video input by default
Adopt standard H.265 high profile compression format to get high-quality
video at much lower bit rate
Intuitive and user-friendly Graphics User Interface ( GUI ), window style
operation by mouse
Multi-type recording: manual / schedule / sensor / motion /analytics recording
Playback : 8 / 16 CH simultaneously playback
Search: time slice, time, event, tag and smart search
Express and flexible backup via USB, network and so on
Pentaplex: preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol
Remote control via Web Client or CMS : preview, playback, backup, PTZ and
configuration
Authorization management, log review and device status review
HDMITM 4K output, true high resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QRCode scanning by mobile phones
Powerful mobile surveillance by smart phones with iOS and Andriod OS
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Model | TD-2708BE-HP | TD-2716BE-HP | |
System | OS | Embedded Linux | |
Video | Analog Video Input | BNC × 8 | BNC ×16 |
BNC interface (1.0Vp-p; 75Ω) | |||
TVI/AHD/CVI: 4K@15fps, 5MP@20fps, 4MP/3MP/1080P/720P/WD1@30fps (live) | |||
IP Video Input | 8CH (up to 16CH) | 8CH (up to16CH) | |
Up to 8MP@30fps | |||
Total Input | 16CH | 24CH | |
Output | HDMITM × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768 | ||
Compression | H.264/H.265 | ||
Multi-screen Display | 1/4/6/8/9/16 | 1/4/6/8/9/13/16/25 | |
Audio | Input | RCA × 8 | |
Output | RCA × 1 (linear, 600Ω) | ||
Two-way audio | Take up channel one audio input | ||
Compression | G.711(U/A) | ||
Record | Resolution | 4K/4K Lite/5MP/5MP Lite/4MP/4MP Lite / 3MP/1080P/720P/WD1/D1 | |
Frame Rate | Analog Channel: | ||
Bit Rate | 32Kbps ~ 8Mbps | ||
Playback | Playback | 8CH | 16CH |
Search | Time slice / time / event / tag /smart search | ||
Smart Search | Highlight colors to display the camera record in a certain period of time, different colors refer to different record events | ||
Function | Play, pause, FF, FB, digital zoom, etc. | ||
Alarm | Mode | Manual, motion, exception, smart event | |
Input | 8CH | 16CH | |
Output | 2CH | 4CH | |
Network | Interface | RJ 45 1000Mbps × 1 | |
Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, NTP, SMTP | ||
Incoming Bandwidth | 32Mbps | ||
Outgoing Bandwidth | 96Mbps | ||
Client Connection | Max. 10 users access | ||
MobileDevice | OS | iOS, Andriod | |
Storage | HDD | SATA× 2, up to 10TB per HDD; E-SATA× 1 | |
Backup | Local Backup | U disk, USB mobile HDD | |
Network Backup | Yes | ||
Port | RS 485 | Yes (half-duplex), connect to PTZ or keyboard | |
USB | USB 2.0 × 1; USB3.0 × 1 | ||
Remote Controller | Optional | ||
Others | Power Supply | DC12V / 4A | |
Consumption | ≤ 15W ( without HDD ) | ≤ 30W ( without HDD ) | |
Dimensions(mm) | 380 × 268 × 45 ( W × D × H ) | ||
Working Environment | -10~50°C, 10%~90% (humidity) | ||
Certificate | CE, FCC | ||
Environmental Protection | Comply with Directive EU RoHS, WEEE, REACH | ||
