System

OS

Embedded Linux

Video

Network Input

32CH IPC input

Network Input Resolution

8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/
960H/D1/CIF

Output

HDMI^TM × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024/ 1024 × 768
VGA: 1920 × 1080 / 1280 × 1024/ 1024 × 768

Screen Display Mode

1/4 /6/8/9/13/16/25/32/36

Compression

H.265S / H.265+ / H.265 / H.264

Audio

Network Input

32 CH IPC audio input

Local Input

RCA × 1 (for two-way audio)

Local Output

RCA × 1

Compression

G.711(U/A)

Record

Resolution

8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/
960H/D1/CIF

Frame Rate

NTSC:30fps; PAL:25fps

Playback

Simultaneous Playback

Max. 16 CH

Search

Time slice / time / event / tag search

Smart Search

Highlighted color to display the camera record in a certain period of time,
different colors refers to different record events

Function

Play, pause, FF, FB, digital zoom, etc.

Decoding Capability

Live View/ Playback

Non-AI Mode:4×4MP@30fps/9×1080P@30fps/16×720P@30fps
AI Mode: 4×3MP@30fps/9×720P@30fps/16×D1@30fps

Alarm

Mode

Manual, sensor, motion, exception, smart events

Input

4CH alarm input; IPC alarm input supported

Output

1CH alarm output; IPC alarm output supported

Triggering

Record, snap, preset, e-mail, etc.

Network

Interface

RJ 45 1000Mbps × 1

Protocol

TCP / IP, IPv4, IPv6, UDP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, HTTP, SMTP,
HTTPs, 802.1x, RTSP, RTP, RTCP, FTP, WebSocket, SNMP, IGMP, ONVIF

Incoming/ Outgoing Bandwidth

192/192 (Mbps)
*When the AI function of the IPC is enabled, the actual incoming bandwidth
(max.bitrate) is more than the set value in the NVR.

Client Connection

Max. 128 users

Face

Face Detection Performance
(AI by IPC)

32 CH

Face Detection Performance
(AI by Device)

2 CH (2MP)

Face Match Performance

No

Statistical Graph of Information

Bar graph

Statistical Mode of Information

Statistics by day, week, month, quarter as well as customized time period

Perimeter Protection

Human/Vehicle Classification
(AI by IPC)

32 CH

Human/Vehicle Classification
(AI by Device)

2 CH (2MP)

Video Metadata

Human/Vehicle Attribute Analysis
(AI by IPC)

Yes

Other Functions

Fisheye

Supports fisheye dewarping via Web Client and mobile APP

Plate Recognition (AI by IPC)

Yes

Mobile Device

OS

iOS, Andriod

Storage

HDD Interface

SATA3.0 × 2, max 10T per HDD

Backup

Local Backup

U disk, USB mobile HDD

Network Backup

Yes

Port

USB

USB2.0 × 2; USB3.0 × 1

RS 485

Yes (full-duplex); connect to PTZ or keyboard

Remote Controller

Optional

Others

Power Supply

DC 12V/3A

Consumption

≤ 10W ( without HDD )

Dimensions (mm)

380 × 268 × 45 ( W × D × H )

Working Environment

-10 ～ 50°C, 10% ～ 90% humidity

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, REACH and WEEE
