System

OS

Embedded Linux

Video

Compression

H.265S/H.265+/H.265/H.264

IP Video Input

8CH IPC input

Resolution

16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/
720P/960H/D1/CIF

Incoming/ Outgoing Bandwidth

160Mbps/160Mbps

*When the AI function of the IPC is enabled, the actual incoming
bandwidth(max.bitrate) is more than the set value in the NVR.

Output

HDMI^TM×1 : 3840 × 2160/1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA ×1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA can be set to output the same or different video source with HDMI^TM

Multi-screen Display

Main output: 1/4/6/8/9 (live view)
AUX output:1/4/6/8/9 (live view)
AI mode: max 8CH (HDMI^TM and VGA output the same video source,
AI by device supported)
Non-AI mode(default mode): max 16CH (VGA can be set to output the same
or different video source with HDMI^TM, AI by device not supported)

Audio

Network Input

8 CH IPC audio input

2-way Audio

RCA × 1

Local Output

RCA × 1

Compression

G.711(U/A)

Record

Resolution

16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/
720P/960H/D1/CIF

Frame Rate

NTSC: 30fps; PAL: 25fps

Playback

Simultaneous Playback

Max 8 CH

Search

Time slice / time / event / tag / smart search

Smart Search

Highlighted color to display the camera record in a certain period of time, different colors refers to different record events

Function

Play, pause, FF, FB, digital zoom, etc.

Decoding Capability

Live View/ Playback

Non-AI   Mode:1×16MP@30fps/4×8MP@30fps/9×3MP@30fps/16×2MP@30fps
AI   Mode:  1×16MP@30fps/4×5MP@30fps/9×2MP@30fps/16×720P@30fps

Alarm

Input

8 CH local alarm input

Output

4 CH

Triggering

Record, snap, preset, e-mail, etc.

Face

Face Detection Performance (AI by IPC)

8 CH

Face Detection Performance (AI by Device)

2 CH (2MP)

Face Match Performance

6 CH

Comparison Capability

18 pictures / second

Face Picture Database

32    libraries 10000 Face Pictures

Face Picture Search

Search by picture is supported

Database Management

Add, modify, delete and search face pictures

Face Picture Adding

Add face pictures through APP, WEB and external import

Face Picture Comparison

Supports allow list, block list and stranger match alarm

Track

Track display on a map

Statistical Graph of Information

Bar graph

Statistical Mode of Information

Statistics by day, week, month, quarter as well as customized time period

Perimeter Protection

Human/Vehicle Classification (AI by IPC)

8 CH

Human/Vehicle Classification (AI by Device)

2 CH (2MP)

Video Metadata

Human/Vehicle Attribute Analysis

Yes (AI by IPC)

Other Functions

Fisheye

Supports fisheye camera access

Plate Recognition (AI by IPC)

Yes

Network

Interface

RJ 45 1000 Mbps × 2

Protocol

TCP/IP, IPv4, IPv6, UDP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, HTTP, FTP, SMTP,
HTTPS, 802.1x, RTSP, RTP, RTCP, WebSocket, SNMP, IGMP, ONVIF

Client Connection

Max. 64 users access

Mobile Device

OS

iOS, Andriod

Storage

HDD Interface

SATA × 1, max 10T

Backup

Local Backup

U disk, USB mobile HDD

Network Backup

Yes

External Interface

RS 485

Yes (full-duplex), connect to PTZ or keyboard

USB

USB 3.0 × 1 ; USB 2.0 × 2

Remote Controller

Optional

Others

Power Supply

DC12V/2A

Consumption

≤ 20W ( without HDD )

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, REACH and WEEE

Dimensions(mm)

300 × 248.5 × 48.1 ( W × D × H )

Working Environment

-10 〜 50 ℃，10% 〜 90% humidity
