Image sensor

1/2.8″ progressive scan CMOSx 4CH

Mini. Illumination

Color：0.005Lux @ (F1.6，AGC ON)；B/W：0.001Lux @(F1.6，AGC ON);0Lux with IR

Image setting

Saturation, Brightness, Contrast, Sharpness, AGC, and AWBadjusted by client software/browser

Shutter Speed

1/1 s – 1/100,000 s

White Balance

Auto/Manual/Indoor/Outdoor

Gain

Auto/Manual

Day & Night

IR Cut filter

Privacy Mask

4CH x 1 Programmable privacy masks

Image Enhancement

DWDR, 3D DNR, Digital zoom, Logo picture Overlay

Angle Adjust

Circular slide 0°~95°，vertically rotate 40°~70°,4CH

Lens

EFL/F/no

4.0mm lens x 4CH, F1.6

FOV

(Horizontalx Vertical) FOV:90°x50°

Working distance

0.2m ~ INF

IR

IR Range

25m (in radius), cover about 2000 square meters, 360°(H) x90°(V)

Smart IR

Yes

Network

Max Resolution

3840x2160(1~30fps)

Stream 0

Panoramic view: 3840×2160,2560×1440,1920×1080(1~30fps)

Stream 1

CH1:1920×1080,1280×720,720×480(1~30fps)

Stream 2

CH2:1920×1080,1280×720,720×480 (1~30fps)

Stream 3

CH3:1920×1080,1280×720,720×480 (1~30fps)

Stream 4

CH4:1920×1080,1280×720,720×480 (1~30fps)

Video compression

H.265+/H.265/H.264+/H.264/MJPEG

Audio compression

G.711 A/U

Protocols

HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP,DHCP, PPPoE

Simultaneous live view

Up to 6 channels

User / Host

Up to 16 users, 3 levels: Administrator, Advanced User and Normal User

Security Measures

User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering

Smart Features

Basic event

Motion detection, video tampering alarm,exception (network disconnected, IP address conflict, SD full, SD error)

Smart Detection

Up to 4 regions configurable: Human/vehicle detection and classification, Face comparison, Intrusiondetection,Line crossing detection, Region

entrance detection,Region exiting detection, Unattended baggage detection, Object removal detection, Scene change detection.

ROI

Up to 4 regions configurable

Alarm Linkage

Upload to FTP/Memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture

System Integration

Alarm Interface

1CH alarm input; 1CH alarm output

Audio Interface

1CH audio input, 2 to 2.4v[p-p] 1kΩ±10%; 1CH audio output (line out), impedance: 600Ω

Network Interface

1 RJ45 10M/100M Adaptive Ethernet (Support PoE+(802.3.at,class 4))

Storage

Built-in memory card slot, support microSD/SDHC/SDXC, up to 256G

API

ONVIF, support TVT SDK and third-party management platform

Client

TVT NVR N9000 1.4.5, TVT NVMS 2.0

Web Browser

IE8-11

General

Power

AC24V,DC24V,PoE+ (802.3.at, class 4), (Max 25W, include IR on)

Working condition

-30°C ~ 55°C (-22 °F ~ 131 °F),90%RH less (non-condensing),Cold start at - 20°C

Storage condition

-40°C ~ 70°C ;≤ 95% RH

Protection

IP 66, IK10, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Material

Aluminum Alloy; Plastic

Dimensions

￠273mm x H 180mm( ￠10.7” x 7”)

Weight

Net weight Approx. 3.26 Kg(7.18 l.b.)

Certification

IK10, IP66,ROHS, CE, FC
