BSI+NIR progressive scan CMOS
Up to 2560x1440 resolution
Mini illumination:
Color: 0.01 lux @ (F1.65 AGC ON)
0 Lux with IR
25x optical zoom, Accurate and fast focusing
WDR, 3D DNR, Smart IR 160m
Smart H.265+/H.265/H.264+/H.264
Intelligent Video content analytics
Smart tracking of human/vehicle
Smart detection and perimeter protection
ONVIF, API and SDK
PoE+ and DC12V
IP66,-40°C~60°C, ADC12 & PC/GF
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
| Camera Module | |||||
| Image sensor | 1/2.7″ progressive scan CMOS, BSI, NIR+ | ||||
| Mini. Illumination | Color：0.01Lux @ (F1.65，AGC ON)；B/W：0.002Lux @(F1.65，AGC ON);0Lux with IR | ||||
| Image setting | Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, etc. adjusted by client | ||||
| Shutter Speed | 50Hz: 1/25s ~1/25,000s; 60Hz: 1/30s ~ 1/30,000s | ||||
| White Balance | Auto/Manual/Indoor/Outdoor | ||||
| Gain control | Auto/Manual | ||||
| Day & Night control | Auto/Manual ,time schedule | ||||
| Iris control | Auto/Manual | ||||
| SNR | ≥52dB | ||||
| 3D DNR | Auto/Manual | ||||
| AE Enhancement | BLC, HLC, WDR | ||||
| Privacy Mask | 4 areas, up to 8 per request | ||||
| Picture overlay | Logo picture could be overlaid on video with 128x128pixels,24bits BMP format | ||||
| OSD overlay | Max 15 characters/line, 8 lines, white or red font color | ||||
| Lens | |||||
| Focus length | f=4.8-120mm lens,25x optical zoom | ||||
| Zoom Speed | Approx. 3.6s (optical zoom, wide-tele) | ||||
| Field of View | Horizontal: 55° ~2.4°±5%; Vertical: 33° ~ 1.4°±5%; Diagonal: 61.5° ~ 2.8°±5% (wide-tele) | ||||
| Working distance | Wide: 1.0m ~ INF; tele: 1.5m ~ INF | ||||
| Aperture Range | F1.65 ~ F3.8 (wide-tele) | ||||
| Iris type | DC-IRIS, 16 Stops | ||||
| IRCut type | Removable IRCut filter, with blue diamond glass to remove image flare and ghost | ||||
| DORI distance | Focus length | Detect(25px/m) | Observe(63px/m) | Recognize(125px/m) | Identify(250px/m) |
| f=4.8mm | 96m(315 f.t.) | 38m(124.7 f.t.) | 19.2m(63 f.t.) | 9.6m(31.5 f.t.) | |
| f=120mm | 2200m(7218 f.t.) | 873m(2864.3 f.t.) | 440m(1443.6 f.t.) | 220m(721.8 f.t.) | |
| PTZ | |||||
| Pan Range | 360°endless | ||||
| Pan speed | Configurable, from 0.1~200°/s; Preset speed: 240°/s | ||||
| Tilt Range | From -10° to 90°,auto flip | ||||
| Tilt Speed | Configurable, from 0.1°~ 200°/s, Preset speed: 240°/s | ||||
| Proportional Zoom | Yes | ||||
| Preset | 360 | ||||
| Cruise | 8 cruises, up to 16 presets for each cruises | ||||
| Trace | 4 traces, record time over 3 minutes for each trace | ||||
| Power off memory | Support | ||||
| Action mode | Preset/Cruise/Trace/Auto Scan/Random Scan | ||||
| 3D Positioning | Support | ||||
| PTZ Position Display | Support | ||||
| Schedule Task | Preset/Cruise/Trace/Random Scan/Boundary Scanning /Dome reboot | ||||
| IR | |||||
| IR Distance | 160m(525 f.t.), dual stack IR LED Array | ||||
| Smart IR | Yes | ||||
| Network | |||||
| Max Resolution | 2560x1440 | ||||
| Main stream | 50Hz: 25fps: 2560×1440,1920×1080,1280×960,1280×720； 60Hz: 30fps: 2560×1440,1920×1080,1280×960,1280×720 | ||||
| Sub stream | 50Hz: 25fps: (704 × 576, 640 × 480, 352 × 288); 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) | ||||
| Third Stream | 50Hz:25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) | ||||
| 60Hz:30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) | |||||
| Video compression | H.265+/H.265/H.264+/H.264/MJPEG | ||||
| H.264 Standard | H.264/AVC codec BP/MP/HP, Level 5.1 | ||||
| H.265 Standard | H.265/HEVC codec MP, level 5.0 | ||||
| Video Bit Rate | 64Kbps to 8Mbps | ||||
| Audio compression | G.711 A/U | ||||
| Audio Bit Rate | 64K bps | ||||
| Protocols | HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP, PPPoE | ||||
| Simultaneous live view | Up to 6 channels | ||||
| User / Host | Up to 16 users, 3 levels: Administrator, Advanced User and Normal User | ||||
| Security Measures | User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering | ||||
| Smart Features | |||||
| Basic event | Motion detection, Video tampering alarm, Exception(Network disconnected, IP address conflict, SD full, SD error) | ||||
| Face recognize | Default off, Detecting max 15 faces at same scene. Detecting, tracking, capturing | ||||
| Road traffic | Vehicle detecting and tracking | ||||
| Smart Detection | Tripwire, Bi-directional tripwire, Illegal intrusion detection, Region entrance detection, Region exiting detection, etc. More VCA per request | ||||
| Smart Tracking | Smart tracking of human or vehicle, auto/manual | ||||
| System Integration | |||||
| Alarm Interface | 1 Alarm input(Dry contact); 1 Alarm output | ||||
| Audio Interface | 1 audio input(MIC in); 1 audio output, line level, impedance,600Ω | ||||
| Alarm Linkage | Alarm actions, such as Preset, Cruise, Track, Memory Card Video Record, Trigger Recording, Upload to FTP/Memory Card, Send Email, etc. | ||||
| Network Interface | 1 RJ45 10M/100M Adaptive Ethernet ,Support PoE+ | ||||
| SD Card Slot | One MicroSD slot, up to 256G | ||||
| RS 485 | N/A | ||||
| BNC | N/A | ||||
| Speaker | N/A | ||||
| Reset button | Yes | ||||
| Heater | Yes | ||||
| Fan | Yes | ||||
| Water removal | Remove water-drops by quick spinning, blow hot air to glass to remove frost, ice | ||||
| API | ONVIF, support TVT SDK and third-party management platform | ||||
| Client | TVT N9000 1.4.5, TVT NVMS 2.0; and the third-party client | ||||
| Web Browser | IE8-11 | ||||
| General | |||||
| Languages | Czech; English, German ; Hungarian ; Italian ; Japanese ; Korean ; Portuguese, Polish; Russian, Romanian, Spanish; Spanish(Mexico);Simplified Chinese; Turkish; Traditional Chinese. | ||||
| Power Supply | DC12V±25%,3000mA ,PoE+ (802.3.at), max 23W include IR ON+PTZ working | ||||
| Working condition | -40°C ~ 60°C (-40°F ~ 140°F), Cold start at - 30°C(30minutes waiting); 90%RH | ||||
| Storage condition | -40°C ~ 70°C ; ≤ 95% RH | ||||
| Protection | 6000V Lightning Protection, Surge Protection and Voltage Transient Protection | ||||
| Material | Aluminum Alloy + Plastic/GF15% | ||||
| Dimensions | Φ 173mm × 268mm (Φ6.8 inch × 10.55 inch) | ||||
| Net Weight | Approx. 2.1 Kg (4.63 lb.) | ||||
| Certification | IP66,IK10(excluding glass window),ROHS,CE,FC | ||||
