Image sensor

1/2.8" progressive scan CMOS image sensor (SONY IMX715)

Max resolution

3840×2160

Mini. Illumination

Color: 0.01 Lux @ (F1.3,AGC ON); B/W:0.002 Lux @(F1.3，AGC ON); 0 Lux with IR

Image setting

Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, etc. adjusted by client

Shutter Speed

60Hz: 1/30s – 1/30,000s; 50Hz: 1/25s~1/25,000s

White Balance

Auto/Manual/Indoor/Outdoor

Gain control

Auto/Manual

Day & Night control

Auto/Manual, time schedule

Iris control

Auto/Manual

SNR

≥52dB

3D DNR

Auto/Manual

AE Enhancement

BLC, HLC, WDR

Digital Zoom

16X

EIS

N/A

Privacy Mask

4 mask areas (ver5.1.1)

Picture overlay

Logo picture could be overlaid on video with 128x128pixels,24bits format

OSD overlay

Max 15 characters/line, 8 lines, white or red font color

Lens

Focus length

f=4.8-154mm,32x optical zoom

Zoom Speed

Approx. 4.6s (optical zoom, wide-tele)

Field of View

Horizontal: 61.3° ~2.18°; Vertical: 36.9° ~ 1.22°; Diagonal: 68.4° ~ 2.5° (wide-tele) ±5%

Image distance

Wide: 1.0m ~ INF; tele: 1.5m ~ INF

Aperture Type

F1.3~F4.8(W-T), HALL_IRIS

IRCut type

Removable IRCF, reflection type

DORI
table

Focus length

f=4.8mm

f=154mm

Detect

143.4m(326.8 f.t.)

4093.8m(8126.6f.t.)

Observe

56.9m(129.7 f.t.)

1624.5m(3250.7 f.t.)

Recognize

28.7m(65.4 f.t.)

818.8m(1625.3f.t.)

Identify

14.3m(32.7 f.t.)

409.4m(812.7 f.t.)

PTZ

Pan Range

360°endless

Pan speed

Configurable, from 0.1~360°/s; Preset speed: 330°/s

Tilt Range

Mechanical -25° to 155°, auto flip at 90°

Tilt Speed

Configurable, from 0.1°~210°/s, Preset speed: 180°/s

Proportional Zoom

Yes

Preset

360

Cruise

8 cruises, up to 16 presets for each cruise (ver5.1.1)

Trace

4 traces, record time over 3 minutes for each trace(ver5.1.)

Power off memory

Support

Action mode

Preset/Cruise/Trace/Auto Scan/Random Scan

3D Positioning

Support

PTZ status display

Support

Schedule Task

Preset/Cruise/Trace/Random Scan/Boundary Scanning /Dome reboot

IR

IR Distance

200m (656 f.t.)

IR type

8pcs of 5W 855nm IR Array, 4groups

Smart IR

Yes

Network

Mainstream

50Hz/25fps: 3840×2160, 2560×1440, 1920×1080, 1280×960, 1280×720
60Hz/30fps: 3840×2160, 2560×1440, 1920×1080, 1280×960, 1280×720

Sub stream

50Hz/25fps (704 × 576, 640 × 480, 352 × 288)
60Hz/30fps (704 × 480, 640 × 480, 352 × 240)

Third Stream

50Hz/25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz/30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Video compression

H.265+/H.265/H.264+/H.264/MJPEG

H.264 Standard

H.264/AVC codec BP/MP/HP, Level 5.1

H.265 Standard

H.265/HEVC codec MP, level 5.0

Video Bit Rate

64 Kbps to 16Mbps

Audio compression

G.711 A/U

Audio Bit Rate

64K bps

Protocols

HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP,
UDP, IGMP, ICMP, DHCP, PPPoE, P2P, RTMP

User / Host

Up to 16 users, 3 levels: Administrator, Advanced User and Normal User

Security Measures

User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption,
IEEE802.1x port-based network access control; IP address filtering

API

ONVIF G/S/T, support TVT SDK and third-party management platform

Client

TVT N9000 1.4.7, TVT NVMS 2.0; and the third-party client, free iOS and Android App

Web Browser

IE8-11 with plug-in; Edge, Chrome, Firefox with plugin free

Smart Features

Basic event

Motion detection, Video tampering alarm, Exception (Network disconnected, IP address conflict, SD full, SD error)

Face recognition

Face detection, capturing (Default off, open per request) face comparison. Max 15 faces at the same times

Road traffic

Vehicle detecting and tracking

Smart Detection

Tripwire, Bi-directional tripwire, Illegal intrusion detection, Region entrance detection, Region exiting detection

Smart Tracking

Support smart tracking of human or vehicle, auto/manual

System Integration

Alarm Interface

1 Alarm input (Dry contact); 1 Alarm output

Audio Interface

1 audio input, line level, 2.0-2.4Vpp, impedance 1KΩ; 1 audio output, line level, impedance,600Ω

Alarm Linkage

Alarm actions, such as Preset, Cruise, Trace, Memory Card Video Record, Trigger Recording,
Notify Surveillance Center, Upload to FTP/Memory Card, Send Email, etc.

Network Interface

1 RJ45 10M/100M Adaptive Ethernet; Support PoE++

SD Card Slot

One MicroSD slot and chamber, up to 256G

Built-in Speaker& Mic

N/A

RS485

N/A

BNC

N/A

Reset button

Yes

Electric Heater &Fan

Yes

Water removal

Remove water-drops by quick spinning

Demist

Active electric heating and air loop

General

languages

Czech; English, German, Hungarian, Italian, Japanese, Korean, Portuguese, Polish, Russian, Romanian,
Spanish, Spanish (Mexico), Simplified Chinese, Turkish, Traditional Chinese

Power

Power consumption

avg. 14W, max 29W, including IR 10W

Power adaptor

AC24V±25%/3000mA, DC24V±25%2500mA

Power over ethernet

PoE++ (802.3.bt,class 6) midspan, network switch, router or high power NVR

Working condition

-40°C ~ 65°C (-40°F ~ 149°F), IR off; -40°C ~ 45°C, IR on; Cold start at - 30°C; 90%RH

Storage condition

-40°C ~ 70°C;  ≤ 95% RH

Protection

6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Shield Material

Aluminum Alloy (ADC12); Polymer (PC+GF15%)

Dimensions

Φ 197mm × 302mm (Φ7.8 inch ×11.9 inch)

Net Weight

Approx. 2.82 Kg (6.22 lb.)

Certification

IP67, IK10, ROHS, CE, FC, KC, BIS, UKCA
