Camera

Image Sensor

1 / 2.8" CMOS

Image Size

1920 × 1080

Electronic Shutter

1 / 3 s ~ 1 / 100000 s

Iris Type

DC-IRIS

Min. Illumination

0.0026 lux@F1.2, AGC ON

Lens Mount

CS

ABF

Yes

Wide Dynamic Range

120dB

BLC

Yes

HLC

Yes

Defog

Yes

Digital NR

3D DNR


Video Compression

Main stream: Smart H.265 / H.265+ / H.265 / Smart H.264 / H.264+ / H.264
Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG
Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240

Main Stream

1080P/720P (60Hz:1~30fps; 50Hz:1~25fps)

Sub Stream

720P/D1/CIF/480 ×240 (60Hz:1~30fps; 50Hz:1~25fps)

Third Stream

D1/CIF/480 ×240 (60Hz:1~30fps; 50Hz:1~25fps)

Bit Rate

64 Kbps ~ 6 Mbps

Bit Rate Type

VBR / CBR

Image Settings

ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen, NR, etc. adjustable through client software or web browser

Audio Compression

G711A/U

ROI

Each ROI to be configured separately

Interfaces

Network

RJ 45

Video Output

No

Audio

1CH audio input; 1CH audio output; 1CH built-in MIC

Storage

Built-in micro SD card slot, up to 256GB

Reset

Yes

Alarm

2CH alarm input; 2CH alarm output

USB

USB port × 1

RS 485

Yes

Functions

Remote Monitoring

Web Browser/TVT NVMS2.0/NVR/mobile APP

Web Browser

IE11(plug-in required)/Chrome 89.0+/Edge 89.0+/Firefox 87.0+/Safari 14.0+

Online Connection

Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTMP, RTCP, PPPoE, DDNS,
SMTP, FTP, SNMP, HTTP, HTTP POST, 802.1x, UPnP, HTTPS, QoS

Interface Protocol

ONVIF

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection; Sensor alarm; SD card full; SD card error; IP address conflict; Network disconnection

Intelligent Analytics

Face detection, face capture, face match, video blur detection, abnormal color detection, scene change detection

General Function

Watermark, video mask, heartbeat, corridor pattern, face exposure

Security

Video encryption, firmware encryption, HTTPS encryption, configuration encryption, failure login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP

PoE

Yes (802.3af)

Face Detection

Face Detection

Pupil distance of a facial image over 20 pixel can be detected

Face Capturing

Output the most effective face snapshots by precise detecting, tracing, capturing, scoring and screening the moving faces

Panorama Capturing

Support panorama capturing and self-defined information overlay, like device ID, time, etc.

Intelligent Light Compensation

No(external supplementary light sources are needed)

Face Picture Database

10000 face pictures

Database Management

Add, modify, delete and search face pictures

Face Picture Adding

Add face pictures through WEB and Face Album Manager Tool

External Face Picture Enrollment

Size: less than 70KB Format: jpg, jpeg

Face Picture Comparison Alarm

Support face trigger modes ，Support allow list, block list, stranger alarms

Others

Power Supply

AC24V/DC12V/PoE

Power Consumption

< 5.5W

Storage Conditions

- 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)

Operating Conditions

- 30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

143 × 79 × 64

Weight ( net )

Approx. 0.65KG

Installation

Wall mounting; ceiling mounting

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
