Camera

Image Sensor

1 / 3" CMOS

Image Size

2560×1440

Electronic Shutter

1 / 1s ~ 1 / 100000s

Iris Type

Fixed Iris

Min. Illumination

0.005 lux @F1.6, AGC ON; 0 lux with IR

Lens

2.8mm@F1.6, Horizontal FoV: 94°;Vertical FoV:50°;Diagonal FoV:115°
3.6mm@F1.6, Horizontal FoV:78°;Vertical FoV:40°;Diagonal FoV:97°

Focus

Fixed

Lens Mount

M12

Day&Night

ICR

Wide Dynamic Range

120dB

BLC

Yes

HLC

Yes

Digital NR

Yes

S/N ratio

≥50dB

Angle Adjustment

Pan: 0°~360°; Tilt:0°~80°;Rotation: 0°~360°


Video Compression

Main  stream:  H.265   /   H.264
 Sub/Third stream: H.265 / H.264 / MJPEG

H.265 Compression Standard

Main Profile@Leve4.1 High Tier

Resolution

4MP ( 2560 × 1440 ), 3MP ( 2304 × 1296 ), 1080P ( 1920 × 1080 ),
720P ( 1280 × 720 ), D1, VGA (640×480), 480× 240, CIF

Main Stream

60Hz: 4MP/3MP/1080P/720P(1~30fps); 50Hz: 4MP/3MP/1080P/720P(1~25fps)

Sub Stream

60Hz: 720P/D1/VGA/CIF (1~30fps);50Hz: 720P/D1/VGA/CIF (1~25fps)

Third Stream

60Hz: D1/480× 240/CIF (1~30fps);50Hz: D1/480× 240/CIF(1~25fps)

Bit Rate

64 Kbps ~ 8 Mbps

Bit Rate Type

VBR / CBR

Image Settings

ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc.
adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces

Network

RJ 45 10M/100M self-adaptive Ethernet port

Video Output

No

Audio

1CH audio input

Storage

Built-in micro SD card slot, up to 256GB

Reset

Yes

Functions

Remote Monitoring

Web browser /TVT NVR/NVMS2.X/Mobile APP

Web Browser

IE11(plug-in required)/Chrome 89.0+/Edge 89.0+/Firefox 87.0+/Safari 14.0+

Online Connection

Support simultaneous monitoring for up to 3 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPs, QoS

Interface Protocol

ONVIF

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection, SD card full, SD card error

Smart Event

Video exception (scene change, video blur and abnormal color detection), line crossing detection, region intrusion detection, abandoned/missing object detection

General Function

Watermark, video mask, heartbeat, corridor pattern

Security

Video encryption, firmware encryption, HTTPs encryption, configuration encryption, illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP/HTTPs

PoE

Yes

IR Distance

20 ~ 30 m

Ingress Protection

IP67

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8mm

61.76m(202.62ft)

24.70m(81.03ft)

12.35m(40.51ft)

6.18m(20.27ft)

3.6mm

79.13m(259.61ft)

31.65m(103.83ft)

15.83m(51.93ft)

7.91m(25.95ft)

Wi-Fi

Wireless Standards

IEEE802.11b/g/n

Frequency Range

2.4GHz ~ 2.4835 GHz

Channel Bandwidth

20MHz

Security

WEP, WPA-PSK/WPA2-PSK

Wireless Range

80m

Transfer Rates

11b:     11Mbps
11g:     54Mbps
11n: up to 150Mbps

Others

Power Supply

DC12V/PoE

Power Consumption

< 5W

Operating Environment

- 30 °C ~ 60 °C (-22°F~140°F);Humidity: less than 95 % (non-condensing)

Storage Environment

- 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

167.6 × 74.7 × 148.2

Weight ( net )

Approx. 0.465KG

Installation

Ceiling mounting; Wall mounting

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
