Camera

Image Sensor

1 / 3 "CMOS

Image Size

2560 × 1440

Electronic Shutter

1 /1 s ~ 1 / 100000 s

Iris Type

Fixed Iris

Min. Illumination

0.003 lux@ F1.0, AGC ON; 0 lux with LED ON

S/N Ratio

≥50dB

Lens

2.8~12 mm @F1.4, H.FoV: 97~33°; V.FoV:52~18°; D.FoV: 115~37°

Focus

Motorized

Lens Mount

Φ14

Wide Dynamic Range

120dB

BLC

Yes

HLC

Yes

Defog

No

Digital NR

3D DNR

Angle Adjustment

Pan: 0°~360°; Tilt: 0°~90°; Rotation: 0°~360°


Video Compression

Main stream: H.265 / H.264

Sub stream: H.265 /H.264 / MJPEG

Third stream: H.265 / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

4MP (2560×1440 ), 3MP (2304×1296 ),1080P ( 1920 × 1080 ),720P ( 1280 × 720 ), D1, VGA(640 × 480), CIF, 480 × 240

Main Stream

60Hz:4MP/3MP/1080P/720P(1~30fps); 50Hz:4MP/3MP/1080P/720P(1~25fps)

Sub Stream

60Hz : 720P/D1/VGA/CIF(1~30fps); 50Hz: 720P/D1/VGA/CIF (1~25fps)

Third Stream

60Hz : D1/CIF/480×240 (1~30fps); 50Hz: D1/CIF/480×240 (1~25fps)

Bit Rate

128 Kbps ~ 8 Mbps

Bit Rate Type

VBR / CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Flip, Image Mirror, NR, etc.

adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces

Network

RJ 45

Video Output

NO

Audio

1CH audio input; 1CH built-in MIC

Storage

Built-in micro SD card slot, up to 256GB

Reset

Yes

Functions

Remote Monitoring

Web Browser/TVT NVMS2.0/NVR/mobile APP

Web Browser

IE11(plug-in required)/Chrome 89.0+/Edge 89.0+/Firefox 87.0+/Safari 14.0+

Online Connection

Support simultaneous monitoring for up to 3 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, SNMP, PPPoE, DDNS, 802.1x, SMTP, FTP, UPnP, HTTPs, HTTP, QoS

Interface Protocol

ONVIF

Storage

Network remote storage; micro SD card storage

Intelligent Analytics

Video exception detection, intrusion detection, line crossing detection and abandoned / missing object detection

Smart Alarm

Motion detection, SD card error, SD card full

General Function

Watermark, video mask, heartbeat, corridor pattern

Security

Video encryption, firmware encryption, HTTPs encryption, configuration encryption, illegal login lock, IP address filtering,

802.1x authentication, basic and digest authentication for HTTP/HTTPs

PoE

Yes (IEEE802.3af)

Supplement light Range

IR range: 30 ~ 40 m

White light range: 30 ~ 40 m

Ingress Protection

IP 67

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8~12mm(W)

59.05m(193.73ft)

23.62m(77.49ft)

11.81m(38.74ft)

5.90m(19.35ft)

2.8~12mm(T)

181.84m(596.58ft)

72.73m(238.61ft)

36.37m(119.32ft)

18.18m(59.64ft)

Others

Power Supply

DC12V/PoE

Power Consumption

< 11.5W

Storage Conditions

- 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)

Operating Conditions

- 30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

217.7 × 80.5 × 80.3

Weight ( net )

Approx. 0.69KG

Installation

Ceiling mounting; wall mounting

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
