Camera

Image Sensor

1 / 1.8 "CMOS

Image Size

2560 × 1440

Electronic Shutter

Auto or manual mode; manual mode: 1 / 3s ~ 1 / 100000 s

Iris Type

Fixed Iris

Min. Illumination

0.0006 lux@F1.0, AGC ON; 0 lux with white light

S/N Ratio

≥50dB

Lens

2.8 mm@F1.0, H.FoV: 110°; V.FoV:61°; D.FoV:131°

3.6 mm@F1.0, H.FoV: 97°; V.FoV: 52.5°; D.FoV:115.5°

Focus

Fixed

Lens Mount

M12

Wide Dynamic Range

120dB

BLC

Yes

HLC

Yes

Defog

No

Digital NR

3D DNR

Angle Adjustment

Pan: 0°~360°; Tilt:0°~90°; Rotation: 0°~360°


Video Compression

Main stream: H.265 / H.264

Sub stream: H.265 / H.264 / MJPEG

Third stream: H.265 / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

4MP(2560×1440), 3MP(2304×1296 ),1080P (1920×1080), 720P (1280×720 ), D1, VGA (640 ×480), CIF, 480×240

Main Stream

4MP/3MP/1080P / 720P( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Sub Stream

720P/D1/VGA/CIF( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Third Stream

D1/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Bit Rate

64 Kbps ~ 8 Mbps

Bit Rate Type

VBR / CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Hue, Contrast,Wide Dynamic, Sharpness, Image Flip, Image Mirror, NR, etc. adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces

Network

RJ 45

Video Output

No

Audio

1CH audio input; 1CH built-in microphone

Storage

Built-in micro SD card slot; up to 256GB

Reset

Yes

Alarm

No

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8mm

48.89m(160.4ft)

19.56m(64.17ft)

9.78m(32.08ft)

4.89m(16.04ft)

3.6mm

58.40m(191.60ft)

23.36m(76.64ft)

11.68m(38.32ft)

5.84m(19.16ft)

Functions

Remote Monitoring

Web Client/TVT NVR/NVMS/mobile APP

Web Browser

IE11(plug-in required)/Chrome 89.0+/Edge 89.0+/Firefox 87.0+/Safari 14.0+

Online Connection

Support simultaneous monitoring for up to 3 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP,HTTP, 802.1x, UPnP, HTTPs, QoS

Interface Protocol

ONVIF

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection, SD card error, SD card full

Intelligent Analytics

Line crossing/region intrusion (human/motor vehicle/non-motor vehicle classification), scene change, video blur and video cast detection, abandoned/missing object detection

General Function

Watermark, video mask, heartbeat, corridor pattern

Security

Video encryption, firmware encryption, HTTPs encryption, configuration encryption, illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP/HTTPs

PoE

Yes , IEEE802.3af

White Light Range

30 ~40 m

Ingress Protection

IP 67

Others

Power Supply

DC12V/PoE

Power Consumption

< 10W

Storage Conditions

- 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)

Operating Conditions

- 30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

217.8 × 80.5 × 80.3

Weight ( net )

Approx. 0.66KG

Installation

Ceiling mounting; Wall mounting

Certificate

CE, FCC

Environmental Protection

Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
