Camera

Image Sensor

1 / 1.8 "CMOS

Image Size

2560 × 1440

Electronic Shutter

Auto/manual; Manual mode: 1 /3s ~ 1 / 100000 s

Iris Type

P-Iris

Min. Illumination

0.0014 lux@F1.5,AGC ON;

0 lux with IR

Lens

2.8~12mm@F1.5, motorized

Field of View

Horizontal：109°~46°; vertical: 74.5°~27.1°; diagonal: 116°~52.4°

Lens Mount

Φ14

Day & Night

ICR

Wide Dynamic Range

120dB

BLC

Yes

HLC

Yes

Defog

Yes

Digital NR

3D DNR

S/N Ratio

≥50dB

Angle Adjustment

Pan: 0°~360°; Tilt:0°~90°; Rotation: 0°~360°


Video Compression

Main stream: H.265+ /  H.265  /  H.264+  /  H.264

Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

4MP ( 2560 × 1440 ), 3MP ( 2304 × 1296 ),1080P ( 1920 × 1080 ),

720P ( 1280 × 720 ), D1, VGA(640 × 480), 480 × 240, CIF

Main Stream

4MP/3MP/1080P / 720P( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Sub Stream

720P/D1/CIF/VGA/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Third Stream

D1/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Bit Rate

64 Kbps ~ 8 Mbps

Bit Rate Type

VBR / CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc.

adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces

Network

RJ 45 10M/100M self-adaptive Ethernet port

Video Output

CVBS output (BNC×1)

Audio

1CH audio input; 1CH audio output

Storage

Built-in micro SD card slot; up to 256GB

Reset

Yes

Alarm

1CH alarm input; 1CH alarm output

Functions

Remote Monitoring

Web Browser/TVT NVMS2.0/NVR/mobile APP

Web Browser

IE11(plug-in required)/Chrome 89.0+/Edge 89.0+/Firefox 87.0+/Safari 14.0+

Online Connection

Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTMP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP,HTTP, 802.1x, UPnP, HTTPS, HTTP POST, QoS

Interface Protocol

ONVIF

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection, sensor detection, SD card error, SD card full, IP address conflict, cable disconnection

Intelligent Analytics

Self-defined

General Function

Watermark, video mask, heartbeat, corridor pattern

Security

Video encryption, firmware encryption, HTTPS encryption, configuration

encryption, illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP/HTTPS

PoE

Yes , IEEE802.3af

IR Distance

50~70 m

Ingress Protection

IP 67

Others

Power Supply

AC24V/DC12V/PoE

Power Consumption

< 12.5W

Storage Conditions

- 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)

Operating Conditions

- 30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

278.3 × 100.2 × 88.7

Weight ( net )

Approx. 1.04KG

Installation

Ceiling mounting; Wall mounting

Certificate

CE, FCC

Environmental Protection

Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
