Low-night color performance
TD-8723IE2N(PE/32M/AR40) adopts BSI and NIR++ sensor which is 2x times Q/E efficiency than last gen, lead to a better color night vision for most city and town scenarios.
Improve IR distance to 400m
The Gen1 adopts 8pcs IR LEDs, each deliver about 700mW energy which is single layer thick film type; the Gen 2 adopts 10pcs IR LEDs, each adopt dual-layers thin film type, which could deliver about 2200mW energy. Thus improve the PTZ night vision distance from 300m to more than 400m in pitch black environment.
Multiple Deep-learning VCA
The built-in 1.5Tops AI engine could support multiple AI rules running at the same time: human/vehicle/no-motor classification, perimeter protection, face detection and capture, ANPR, human/vehicles smart-tracking, etc.
Network safety and data privacy protection
The gen2 remove hundreds of item network safety risk and comfort to GDPR and NDAA regulations.
ONVIF protocol, API
This PTZ family conforms to the ONVIF, ensuring interoperability between surveillance video products regardless of manufacturers.
Strong protection for harsh weather
The gen2 keep full-metal housing, IP67 water immersion and IK10 vandalism resistant which support long-time working harsh weather such as: windstorm, sea salty corrosion, desert and high-land strong sun radiation. Built-in 20Watt high power electric heater supports working under -40℃ low temperature.
Rich accessories
Various mounting brackets including junction box,
50Watt hi-power PoE Midspan or AC24V adaptor support flexible in-field wiring and mounting.
Pulsuz Çatdırılma 100 AZN yuxarı bütün sifarişlərə şamil olunur
Bütün məhsullara 100% zəmanət verilir
1gün ərzində məhsulları geri qaytarma edə bilərsiz
Covid-19 Məlumatı: Çatdırmağa davam edirik.
Camera Module | |||||
Image Sensor | 1/2.8" progressive scan CMOS image sensor, with BSI and NIR+ | ||||
Max Resolution | 1920x1080 | ||||
Mini. Illumination | Color:0.00125Lux @ (F1.65, AGC ON); B/W:0.00025Lux@ (F1.65, AGC ON); 0Lux with IR | ||||
Image Setting | Saturation, Brightness, Contrast, Sharpness, AGC, etc. adjusted by client | ||||
Shutter Speed | 60Hz: 1/30s – 1/30,000s;50Hz:1/25s~1/25,000s | ||||
White Balance | Auto/Manual/Indoor/Outdoor | ||||
Gain Control | Auto/Manual | ||||
Day & Night Control | Auto, Manual, Timer, Schedule. | ||||
Iris Control | Auto/Manual | ||||
SNR | ≥52dB | ||||
3D DNR | Auto/Manual | ||||
AE Enhancement | BLC, HLC, WDR | ||||
Digital Zoom | 16X | ||||
Electronical Stabilizer | N/A | ||||
Optical Defog | N/A | ||||
Privacy Mask | Up to 4 privacy masks | ||||
Picture Overlay | Logo picture could be overlaid on video with 128x128pixels,24bits format | ||||
OSD Overlay | Max 15 characters/line, 8 lines, white or red font color | ||||
Lens | |||||
Focus Length | f=4.8-154mm,32x optical zoom | ||||
Zoom Speed | Approx. 4.4s | ||||
Field of View | Horizontal: 59.38° ~ 2.28°; Vertical: 35.74° ~ 1.29°; Diagonal: 66.28° ~2.61°; | ||||
Object to Lens | wide: 1.0m ~ INF; tele: 1.5m ~ INF | ||||
Aperture type | F1.65-F4.70(W-T), HALL-IRIS, support auto/manual | ||||
IRCUT Filter | Removable IRCUT filter (Reflection type) | ||||
DORI Table | Focus length | Detect | Observe | Recognize | Identify |
f=4.8mm | 73.5m(241.1 f.t.) | 29.2m(95.7 f.t.) | 14.7m(48.22 f.t.) | 7.35m(24.11 f.t.) | |
f=154mm | 1912.6m(6275 f.t.) | 759.1m(2490.6f.t.) | 382.5m(1254.9f.t.) | 191.3m(627.5f.t.) | |
PTZ | |||||
Pan Range | 360°endless | ||||
Pan Speed | Configurable, from 0.1~240°/s; Preset speed: 240°/s | ||||
Tilt Range | From -25° to 155°, auto flip at 90° | ||||
Tilt Speed | Configurable, from 0.1°~180°/s, Preset speed: 180°/s | ||||
Proportional Zoom | Yes | ||||
Preset | 360 | ||||
Cruise | 8 cruises, up to 16 presets for each cruises | ||||
Trace | 4 traces, record time over 3 minutes for each trace | ||||
Power off Memory | Support | ||||
Action Mode | Preset/Cruise/Trace/Auto Scan/Random Scan | ||||
3D Positioning | Support | ||||
PTZ Position Display | Support | ||||
Schedule Task | Preset/Cruise/Trace/Random Scan/Boundary Scanning /Dome reboot | ||||
Supplement Light | |||||
Light Distance | 400m (1,312 f.t.) | ||||
IR Type | 8pcs IR LED and 2pcs IR VCSEL, 850nm | ||||
Smart IR | Yes, support facial and ANPR priority | ||||
Video | |||||
Mainstream | 50Hz/25fps: 1920×1080,1280×960,1280×720; 60Hz/30fps: 1920×1080,1280×960,1280×720 | ||||
Sub Stream | 50Hz/25fps: 704× 576, 640 × 480, 352 × 288; 60Hz/30fps: 704 × 480, 640 × 480, 352 × 240 | ||||
| Third Stream | 50Hz/25fps:1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288. 60Hz/30fps:1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240 | ||||
Video Compression | Smart H.265+/H.265/H.264+/H.264/MJPEG | ||||
H.264 Standard | H.264/AVC codec BP/MP/HP, Level 5.1 | ||||
H.265 Standard | H.265/HEVC codec MP, level 5.0 | ||||
Video Bit Rate | 32 Kbps to 16Mbps | ||||
Audio | |||||
| Audio Compression | G.711 A/U | ||||
| Audio Bit Rate | 64K bps | ||||
Network | |||||
Protocols | HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP, PPPoE, P2P, RTMP | ||||
User / Host | Up to 16 users, 3 levels: Administrator, Advanced User and Normal User | ||||
| Security Measures | User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering | ||||
API | ONVIF G/S/T, support TVT SDK and third-party management platform | ||||
Client | TVT N9000 1.4.7, TVT NVMS 2.0; and the third-party client, free iOS and Android App | ||||
Web Browser | IE8-11 with plug-in; Edge, Chrome, Firefox with plugin free | ||||
Event | |||||
| Basic Event | Motion detection, video tampering alarm, alarm input, alarm output, exception ( (Network disconnected, IP address conflict, SD full, SD error) | ||||
| Smart Event | Line crossing detection, region entrance detection, object removal detection, intrusion detection, region exiting detection, audio exception detection | ||||
Smart Tracking | Manual/Auto-tracking of human/no-motor vehicle/motorized vehicle(ver5.1.1) | ||||
| Alarm Linkage | Alarm actions, such as Preset, Cruise, Trace, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card, Send Email, etc. | ||||
Deep-learning Function | |||||
Face Capture | Detecting multiple faces in the same scene. Support detecting, capturing, grading, and output the best. | ||||
Face Comparison | (Default off) Yes | ||||
Perimeter Protection | Line crossing, Intrusion, Region entrance, Region exiting. Support alarm triggering by specified type. | ||||
Road Traffic and Vehicle Detection | |||||
Road traffic | Support vehicle detection and tracking(ver5.1.1). | ||||
System Integration | |||||
Alarm Interface | 2 Alarm input (Dry contact); 2 Alarm output | ||||
Audio Interface | 1 audio input, line level, 2.0-2.4Vpp, impedance 1KΩ; 1 audio output, line level, impedance,600Ω | ||||
| Alarm Linkage | Alarm actions, such as Preset, Cruise, Trace, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card, Send Email, etc. | ||||
Network Interface | 1 RJ45 10M/100M Adaptive Ethernet | ||||
SD Card Slot | One MicroSD slot and chamber, up to 256G | ||||
Built-in Speaker | N/A | ||||
RS485 | Half-duplex, Pelco-P/D | ||||
| BNC | N/A | ||||
Reset Button | Yes | ||||
Heater &Fan | Built-in electric fan for heat sink, Built-in electric heater for cold start. | ||||
Water Removal | Remove water-drops by quick spinning | ||||
Demist | Active electric heating and air loop to lens glass to removal the Frost and Fog | ||||
General | |||||
| Languages | Czech; English, German; Hungarian; Italian; Japanese; Korean; Portuguese; Polish; Russian; Romanian; Spanish; Spanish (Mexico); Simplified Chinese; Turkish; Traditional Chinese. Etc. | ||||
Power Supply | DC24V/AC24V3000mA±25%, PoE++ (802.3.bt, class 6), avg 13.5watt, max 51Watt(IR 10Watt, Heater 10Watt) | ||||
Working Condition | -40°C~70°C (-58°F ~ 158°F), IR off; -40°C~55°C, IR on; Cold start>=- 40°C (1 hour waiting); 90%RH | ||||
Storage Condition | -40°C ~ 70°C; ≤ 95% RH | ||||
Housing | Aluminum Alloy | ||||
Dim. & Weight | ￠219.9mm x H 358.5mm( ￠8.7inch x 14.1 inch), Net weight Approx. 6.0 Kg (13.22 lb.) | ||||
Approval | |||||
EMC | FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011+A1: 2014); | ||||
Certification | CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2017), BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); | ||||
Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) | ||||
Protection | IP67(IEC 60529-2013), IK10 (IEC 62262:2002),6000V Lightning Protection, Surge Protection and Voltage Transient Protection | ||||
